WX-CS Intelligent Dehumidifier
The device employs semiconductor thermoelectric cooling technology for high-efficiency dehumidification, featuring compact design ideal for space-constrained installations
- Core Advantages
- Technical Parameter
-
1. Employs semiconductor thermoelectric cooling technology for high-efficiency dehumidification, featuring compact design ideal for space-constrained installations.
2. Effectively reduces humidity inside electrical control cabinets by condensing internal water vapor into liquid and draining it outside the unit, thus preventing moisture-related issues and ensuring reliable operation.
3. Integrates power supply and control into a compact design, featuring real-time temperature and humidity display, adjustable threshold settings, and functions such as heating control, cooling, and alarm output.
4. Offers a comprehensive alarm system that includes alerts for temperature and humidity sensor disconnection, dehumidification failure, fan stoppage, and high-temperature or high-humidity conditions, ensuring the unit operates safely and reliably.
5. Includes an automatic defrosting mechanism that engages during prolonged operation to maintain dehumidification efficiency.
6. Equipped with a dedicated RS485 communication interface utilizing the MODBUS RTU protocol for data transmission, remote monitoring, parameter adjustment, and fault reporting.
7. Meets Level 4 EMC compliance according to GB/T 17626.4-2018 standards, ensuring dependable performance under strong electromagnetic interference.
8. Built with professional-grade moisture protection to support long-term, stable operation in high-humidity environments. -
Operating power supply
Operating environment
Humidity measurement range
Temperature measurement range
Dehumidification method
Humidity control adjustment range
Communication interface
Machine power
Operating altitude
Insulated voltage-resistant housing and terminal
Insulation resistance
85~265V50Hz
-20°C~60°C
10%RH~95%RH±3%
-9°C~60℃℃±1°C
Automatic/manual
30~90%RH
RS485 MODBUS protocol, remote data transmission (optional)
15~65W±10%
≤2000M
> AC2.5kV high and low voltage
≥100Ω
